The Silicon Bronze Rod for Wear Parts is a high-performance material designed for demanding applications in industries like marine, electrical, and machinery. Known for its excellent corrosion resistance, high strength, and versatility, this copper alloy is ideal for parts that require durability and resistance to wear. It combines the best qualities of copper and silicon, ensuring long-lasting performance even in the harshest environments. Available in a range of sizes and grades, this rod can be customized to meet specific project requirements, making it an essential choice for engineers and manufacturers worldwide.
Product Description
The Silicon Bronze Rod for Wear Parts is a superior alloy composed of copper, silicon, and other elements, delivering exceptional properties for mechanical and industrial applications. This material is particularly noted for its resistance to corrosion, particularly in environments where exposure to moisture or harsh chemicals is common, making it an ideal choice for marine and outdoor equipment.
In addition to its corrosion resistance, silicon bronze is known for its excellent strength-to-weight ratio and superior fatigue resistance, which makes it perfect for use in wear parts that undergo constant stress. Whether it’s for high-speed machinery, structural components, or underwater equipment, the silicon bronze rod stands out for its ability to retain strength and integrity over time, reducing the need for frequent replacements.
The rod’s excellent machinability also allows for easy processing into different shapes and sizes, making it highly adaptable for custom manufacturing and fabrication. Its smooth surface finish ensures that it is aesthetically pleasing, adding value to both functional and decorative applications.
Available in a variety of grades such as C65500 and C51900, the silicon bronze rod is versatile and can be customized according to your specific application needs, whether for wear parts, bushings, gears, or more. This makes it an essential material for industries such as electrical, automotive, aerospace, and more.
| Silicon bronze alloy series composition,%max | |||||||
| Type | Cu（%） | Pb（%） | Fe（%） | Zn（%） | Mn（%） | Si（%） | Ni（%） |
| QSi3-1 | Other | 0.03 | 0.3 | 0.5 | 1.0-1.5 | 2.7-3.5 | 0.2 |
| QSi1-3 | Other | 0.15 | 0.1 | 0.2 | 0.1-0.4 | 0.6-1.1 | 2.4-3.4 |
| QSi3.5-3-1.5 | Other | 0.03 | 1.2-1.8 | 2.5-3.5 | 0.5-0.9 | 3.0-4.0 | 0.2 |
| C65100 | Other | 0.05 | 0.8 | 1.5 | 0.7 | 0.8-2.0 | 0.2 |
| C65500 | Other | 0.05 | 0.8 | 1.5 | 0.5-1.3 | 2.8-3.8 | 0.6 |
| CuNi2Si | Other | <0.02 | <0.2 | - | <0.1 | 0.4-0.8 | 1.6-2.5 |
| Parameter | Description |
|---|---|
| Material | Silicon Bronze (CuSi) |
| Alloy Grades | C65500, C51900, C63000, C95400 |
| Diameter | 3mm to 100mm (customizable) |
| Length | Customizable as per client requirements |
| Finish | Smooth, high-quality surface finish |
| Tensile Strength | High (varies by alloy grade) |
| Corrosion Resistance | Excellent (ideal for marine environments) |
| Machinability | Excellent (easy to process and fabricate) |
| Welding Compatibility | Excellent (easy to weld) |
Corrosion Resistance: Silicon Bronze is highly resistant to corrosion, especially in marine environments and industries exposed to moisture or harsh chemicals. This makes it ideal for underwater and coastal applications.
High Strength: The copper-silicon combination provides excellent tensile strength, ensuring the material can withstand high-stress and heavy-duty applications, from machinery components to marine hardware.
Fatigue Resistance: Silicon Bronze has superior resistance to fatigue, ensuring that parts maintain their performance over time even in high-stress environments.
Excellent Machinability: The rod can be easily machined into a variety of custom parts, including gears, bushings, and shafts, making it versatile for different applications.
Customizable Sizes: Available in various sizes and grades, the silicon bronze rod can be customized to meet the specific requirements of your project, ensuring a perfect fit for your application.
Widely used in marine hardware (ship propeller shafts, valve stems), valve components in water treatment systems, gear bushings in industrial gearboxes, and textile machinery parts (loom components). It is ideal for wear surfaces in pumps, compressors, and hydraulic systems where friction and corrosion resistance are critical.
What applications are best suited for Silicon Bronze Rods?
Silicon Bronze Rods are ideal for wear parts, marine hardware, electrical components, automotive parts, and machinery components that require high corrosion resistance and durability.
Can the Silicon Bronze Rod be customized to fit specific project requirements?
Yes, we offer customization for diameter, length, and alloy grade to meet your specific needs, ensuring a perfect fit for your project.
How does Silicon Bronze perform in harsh environments?
Silicon Bronze offers excellent corrosion resistance, especially in marine environments, and performs exceptionally well in applications exposed to moisture, seawater, and chemicals.
Is this material easy to machine and fabricate?
Yes, Silicon Bronze is known for its excellent machinability, making it easy to process into different shapes and sizes for various applications, from bushings to gears.
What are the available grades for Silicon Bronze Rods?
We offer various grades of Silicon Bronze, including C65500, C51900, and C63000, which can be chosen based on your specific performance requirements.
